LGMA Warehouse Forklift Capacity and Lift Height Selection Guide
To address the specific equipment selection requirements of warehouse operations, LGMA has optimized forklift configurations for various working conditions based on actual operational needs. When purchasing a forklift, it is essential to match the equipment capacity and lift height parameters appropriately based on the actual load weight and available workspace dimensions. LGMA LC series of internal combustion counterbalanced forklifts and rough-terrain forklifts covers a range of specifications to accommodate various standard and specialized warehouse environments.
Rated Load and Model Matching
Light-duty Operations: For handling small to medium-sized components, the LGMA LC-15 to LC-25 forklifts are suitable. Models in this range have rated loads of 1,500 kg to 2,500 kg, with wheelbases set between 1,400 mm and 1,600 mm.
Standard Material Handling: For standard pallet logistics operations, the LGMA LC-30 and LC-35 forklifts are suitable. With rated capacities ranging from 3,000 kg to 3,500 kg, these models are best suited for standard warehouse applications.
Heavy-Duty Industrial Warehousing: For warehouses storing large mechanical components and raw materials, the LC-80 to LC-100 forklifts are suitable. With a maximum rated load of 10,000 kg and equipped with high-displacement engine systems, these models are capable of lifting and moving extremely heavy materials.
Site Height Restrictions and Lifting Height Parameters
Forklift dimensions must be selected based on actual measurements of the warehouse’s internal structural layout.
Overall Height and Door Clearance: The height of the forklift overhead guard determines whether it can pass through warehouse doors and clear low obstacles. The LC-15 forklift has a total height of 2,050 mm; the LC-45 forklift, with a higher rated load capacity, has a total height of 2,230 mm. Select the appropriate model by comparing it with the warehouse’s minimum door header height.
Maximum unloading height: For high-rack operations and outdoor yards, Shandong LGMA LM Series off-road forklifts offer a maximum unloading height of 4,000 mm, meeting high-level loading and unloading standards.
Free Lift Height: When operating inside containers or in covered spaces, the mast must be able to lift cargo without extending outward. The LC series models provide a free lift height of 100 mm to 210 mm, meeting basic lifting requirements in confined spaces.
Visibility Configuration and Adaptability to Complex Operating Conditions
In addition to core load parameters, the design of structural components also contributes to operational precision and safety.
Structure and Instrumentation: The entire LGMA forklift series features a wide-view mast structure, which physically increases the operator’s forward field of vision and reduces the likelihood of collisions caused by blind spots. The control panel is equipped with digital display instruments that provide real-time data.
Terrain Adaptability: For unpaved surfaces or outdoor construction, off-road forklifts such as the LM838 are equipped with a four-wheel-drive system. With an overall height of 2,750 mm and generous ground clearance, these models are suitable for non-standard warehouse sites with significant potholes or slopes.
Frequently Asked Questions
Q1: Why can’t a 3-ton forklift lift a 3-ton load when raised to its maximum height?
A: The higher the load is lifted, the further forward the forklift’s center of gravity shifts, resulting in a decrease in actual lifting capacity. When selecting a LGMA forklift, if the top shelf of a rack requires a 2-ton load, we recommend purchasing a forklift with a rated capacity of 3 tons to ensure safety during high-level operations.
Q2: What should I do if the warehouse aisles are very narrow and the forklift has difficulty turning?
A: When selecting a forklift, pay close attention to the “minimum turning radius” and “right-angle stacking aisle width.” For extremely narrow aisles, choose the LGMA LC-15 or LC-20 lightweight models with shorter wheelbases to reduce the number of times you have to back up due to misalignment.
Q3: When operating inside containers, the mast always hits the top of the container. How can this be resolved?
A: LGMA forklifts can be equipped with a “three-stage fully free-lift mast.” With this mast, the outer mast height remains constant during the initial lifting phase, while only the inner mast moves up or down, ensuring the forklift can operate normally in height-restricted spaces such as inside containers.
Conclusion
LGMA is committed to providing forklifts tailored to various operating conditions, ensuring the precise selection of forklift specifications to match the physical environment of the warehouse.
